Features

  • TCP/IP & Network interfaces
    - IP enabled distributed access control system by ethernet (DHCP or static IP) and RS485 interfaces
  • Power over Ethernet
    - communication and power over a simple CAT5 or 6 cable/supplies up to 600mA of 12 Vdc to locking devices
  • Enterprise-level access control capacity
    - controls up to 40,000 users, 128 time schedules, 128 access groups and 64 zones
  • IP65 weatherproof structure - rugged structure for outdoor installation, operates between -20'C ~ 50'C
  • Easier installation & operation - POE, direct lock relay and Wiegand connection/ command card operation (add/delete users)
  • Sleek & aesthetic design - slim and sleek size for narrow door frames/ multi-color LED & buzzer for indication

Specifications

CPU
400MHz DSP
Memory
8MB FLASH + 16MB SDRAM
RFCard options
13.56 MHz Mifare
125 KHz EM Prox
125 KHz HID Prox
Network Interfaces
TCP/IP, RS485
Sound
Multi-tone buzzer
Indicator
Multi-color LED
RTC
Lithium-ion rechargeable batteries
I/O
Relay x 1
Tamper x 1,
Switch input x 2
Wiegand x 1 (input/output switchable)
Accessories
Extension bracket, power adaptor, Secure I/O, plastic stand
Power
12Vdc, POE(optional)
Operating Temperature
-20~50°C
Size
130 x 45 x 27mm ( H x W x D )
Certificates
CE, FCC, KCC, ROHS
